Brooks firetracker FT1020G3 FDCIE - During Restart

Operation Manual
FT1020G3 Rev 2.4
89
Automatically after download of S/W via
EBLWin.
FFD, WASV SSD, S/W
64
, SSW 00 (+50)
63
Automatically (by the S/W itself) S/W
watchdog.
FFD, WASV SSD, S/W, SSW
65
13
66
Automatically due to external disturbance.
67
FFD, WASV SSD, S/W, SSW
65
01, 02 alt.
04-12 &14-
20
Note: During a restart, the fault output (relay) for the Fault TX will be "activated" for
few seconds, the supervised 24 V
DC
outputs S0-S3 will not be supervised and S0-S3
programmed as normally high will be low for few seconds.
Explanation of Restart Codes
• Code 00 appears after manual power on/off or S/W download.
• Code 03 will appear after a normal restart.
• Code 13 is always followed by an address, to be noted.
• Code 25 appears after download of SSD and automatic restart.
• Code 50 will appear only if the FDCIE has an MMI board.
• Code 53 will appear only if the SDCIE has an MMI board.
Note: Code 00 – 49 = Main board restart. Some data might be lost, see above.
Code 50 – 99 = MMI board restart. No data is lost.
20.3 During Restart
During "restart", no fire alarms will be activated and the following is shown on the display:
And after few seconds (the control panel starts the normal restart procedures else see
Memory fault below):
Booting......
A fault will be generated and the following text message will be shown in the display and
the buzzer will sound:
64
The old S/W will be deleted.
65
Depending on the restart reason, also the SSW may be deleted.
66
Always followed by an address.
67
If this happens, call for service personnel / engineer. Depending on the restart reason, also the SSW might be deleted.
