The AA alarm has to be acknowledged within an acknowledgement time and reset within
an investigation time, otherwise the output(s) for routing equipment (Fire Brigade TX) will
be activated. See FT1020G3 Technical / Ptogramming Manual for more information
regarding the AA function. Acknowledgement and reset of the AA alarm can be performed
on an AA unit 1736. See also chapter "
Alert Annunciation", page 59.
First alarm: 010-01 Alarm number 1 (of 1)
Alert annunciation
Zone Address
010-01 SMOKE
User definable alarm text for 010-01.
1 zone in alarm
.Ackn. Alert.
Menu annunciation
Note: The "Ackn. alert annunciation" text is only visible if an AA alarm is activated.
15.5 Co-Incidence Alarm (2-Address / -Zone Dependence)
The co-incidence alarm is programmed via EBLWin for the alarm points/zones in question.
When only one zone or one zone / address (alarm point) is in alarm status, the FDCIE
buzzer sounds (0.8 / 5 sec.) and there is a Co-incidence alarm presentation in the display.
Note that LEDs "Fire" (L1) are not indicating a co-incidence alarm.
The co-incidence alarm will be automatically Reset after 5 minutes or via the "Reset"
button (P3). See chapter "Alarm reset", page 58.
Example; Co-incidence alarm zone 123, address 45 (within zone 123):
CO-incidence alarm
Zone Address
123-45 SMOKE
User definable alarm text for 123-45.
Menu
If more than one Co-incidence alarm not dependent on each other are activated, the LEDs
"SEVERAL ALARMS" (L6) are blinking and the Co-incidence alarms will be automatically
scrolled (each 5
th
second).
If two or more zones or alarm points (zone / addresses) dependent on each other are in
alarm status at the same time, normal fire alarm (see above) will be activated in the system.
The co-incidence alarm function can be turned on / off via a time channel.
