7 Technical Address / Presentation Number
7.1 Technical Address for COM Loop Units
The technical number “NN N NNN” is used when programming any unit connected to the
COM loops.
Technical number is also used to identify which unit has generated a fault.
• The addresses don't have to be in sequence.
• The connections on the COM loop don't have to be in sequence.
• The technical address can be set to 001 – 255.
• With the programming tool 4414E, the units can also be set to 000 (factory setting).
If the auto-addressing function should be used, the units on the loop must have technical
address 000. See the Technical Manual for the system.
NN N NNN
00-29 0-3 001 - 255
The control unit addresses
(numbers), Don’t have to be in
sequence.
The connections to the TLON
network don’t have to be in
sequence.
The address is set with a PC
SW; TLON Manager
COM loop number
The technical address on the COM loop.
The addresses don't have to be in
sequence.
The connections on the COM loop don't
have to be in sequence.
The address is for each unit set with
the programming tool 4414.
Notes:
Maximum of 1020
29
COM loop (technical) addresses can be used in one Control Unit.
A brand new detector is factory set to COM loop (technical) address 000. If a detector
is connected on a COM loop without setting up an address (001 – 255), the detector
LEDs will start blinking every second, indicating that the detector has not been
addressed.
7.2 Presentation Number
For each fire alarm point / input / zone, a presentation number NNN-NN has to be
programmed.
The presentation number is shown in the FDCIE display, alarm presentation unit 1728 and
alert annunciation unit 1736 to identify the point / zone activating fire alarm. It is also used
to disable / re-enable fire alarm points / zones and as a trigger conditions in the control
expressions to activate programmable outputs.
Together with the presentation number, a user definable 40 characters text message
(alarm text) can be displayed (if programmed).
NNN NN
001-999 00-99
Zone number
01 – 99 = The address within the zone.
00 = Only the zone number will be displayed,
e.g. used for conventional zone line inputs.
29
Since (technical) address 000 cannot be used, the total number of addresses is 4 x 255 = 1020
