Brooks firetracker FT1020G3 FDCIE - 20 Restart; Safe Shut down; Restart Table; Table 16 Data Affected by Restart

Operation Manual
FT1020G3 Rev 2.4
88
20 Restart
A restart may delete some data in FT1020G3. Below follows an explanation of the different
data and abbreviations and a table describing the different reset alternatives and how the
data respectively is affected (cold or warm restart).
FF = Fire alarms and Faults.
D = Disablements
FFD = Fire alarms, Faults and Disablements.
SSW = Sensor min. / max. values & performance factor, passwords
62
, supervised
output calibration values and event logs.
WASV = Week Average Sensor Values
SSD = Site Specific Data, i.e. all the installation programming created and
downloaded via EBLWin.
S/W = Software, i.e. the EBL512 G3 system program.
The date & time and alarm counter value is stored in the memory of the real time clock,
i.e. the value will be retained also after the FDCIE has been powered down.
Note: After any restart, a new week average sensor value will be calculated within two
minutes for all the analogue smoke detectors. During these two minutes all fire alarms
from analogue smoke sensors will be suppressed. Thereafter a new average sensor
value will be calculated each week.
20.1 Safe Shut Down
Safe shut down of Control Unit via menu H8/S6 will save the SSW data in a Flash ROM
in FT1020G3. Before the first "Safe shut down" of the Control Unit, this memory is empty.
After each "Safe shut down" the latest SSW data is saved (Safe shut down will not save
the week average sensor values).
When FT1020G3 is powered up, a restart takes place and the RAM (working memory) will
read the SSW data saved in the Flash ROM.
20.2 Restart Table
Table 16 below describes the different reset alternatives and how the data is affected.
Table 16 Data affected by restart
Action Data Deleted Data not Deleted
Restart
Code
Power down and then power up again. (both
mains and batteries disconnected)
SSW, FFD,
WASV
SSD, S/W 00 (+ 50)
63
Via menu H8/S5 Safe shut down of Control
Unit.
FFD, WASV SSD, S/W, SSW
00 (+50)
63
03 (+53)
63
Via RESET button on Main board 5010. If
this reset is done in the middle of a process,
also the SSW might be deleted.
FFD, WASV SSD, S/W, SSW 03
Via RESET button on MMI board
SSD, S/W, SSW
FFD, WASV
53
Reset command via EBLWin or TLON
Manager.
FFD, WASV SSD, S/W, SSW 03 (+53)
63
Automatically after download of Site Specific
Data (SSD) via EBLWin.
FFD, WASV SSD, S/W, SSW 25
62
Changed via menu H10
63
Code 50 / 53 only if the FDCIE has an MMI board (5011).
