Brother MFC-8380DN Service Manual

3-25
Confidential
■ Error code 88
Paper jam inside the machine
■ Error code 89
Incorrect paper size in duplex printing
Jam Inside
Open the Front Cover, pull out the Drum Unit completely and remove
the jammed paper.
<User Check>
• Check if the paper is jammed around the removed drum unit. If jammed, remove it.
Step Cause Remedy
1
Harness connection failure of high
voltage power supply PCB ASSY.
Check the harness connection of the high
voltage power supply PCB ASSY and
reconnect it.
2
Registration rear actuator catching
on some position
Correct catching of the registration rear
actuator.
3
Registration rear sensor failure Check the sensor performance following
the procedure described in “Maintenance
mode 32”. If any problem occurs, replace
the high voltage power supply PCB ASSY.
4 Main PCB failure Replace the main PCB ASSY.
Check Paper size
Reload correct paper.
<User Check>
• Use the A4 size or letter size paper.
Step Cause Remedy
1
Registration rear sensor failure Check the sensor performance following
the procedure described in “Maintenance
mode 32”. If any problem occurs, replace
the high voltage power supply PCB ASSY.
2 Main PCB failure Replace the main PCB ASSY.

Brother MFC-8380DN Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Scan to	e-mail, FTP, OCR, USB
Input color depth	48 bit
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
Maximum number of copies	99 copies
N-in-1 copy function (N=)	4, 9, 16, 25
Copy speed (black, normal quality, A4)	30 cpm
Faxing	Mono faxing
Fax memory	500 pages
Modem speed	33.6 Kbit/s
Total input capacity	500 sheets
Total output capacity	150 sheets
Multi-Purpose tray input capacity	50 sheets
Auto document feeder (ADF) input capacity	20 sheets
Internal memory	64 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	56 dB
Display	LCD
Market positioning	Home & office
Custom media sizes	(69.8 - 216) x (116 - 406.4) mm
Dimensions (WxDxH)	531 x 451 x 475 mm
Networking features	10/100 Base-TX
All-in-one functions	Copy, Fax, Scan
Maximum internal memory	0.576 GB
Color all-in-one functions	scan, n
Compatible operating systems	Linux, Windows 2000, XP/2003, Vista, XP, Mac OS X 10.3.9
Maximum print size	216 x 297 mm
Media weight (tray 1)	60 - 105 gsm
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
Non-ISO print media sizes	Executive
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Supported network protocols (IPv4)	IPv4, IPv6
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	85 W
Power consumption (PowerSave)	19 W
Power consumption (average operating)	680 W
Package weight	21100 g
