Brother MFC-8380DN Service Manual

3-29
Confidential
■ Error code A2
During scanning, 90 cm or longer of a document is detected
■ Error code A3
Document rear sensor is not turned on when feeding the document
■ Error code A4
ADF cover opened (CIS model only)
Document Jam
Clear the scanner jam, then press the Stop Key.
<User Check>
• Check if the document is jammed in the ADF. If it is jammed, remove it.
Step Cause Remedy
1
Document rear actuator catching
on some position.
Correct catching of the document rear
actuator.
2 Document rear sensor failure Replace the document rear sensor.
3 Main PCB failure Replace the main PCB ASSY.
Document Jam
Clear the scanner jam, then press the Stop Key.
<User Check>
• Check if the document is jammed in the ADF. If it is jammed, remove it.
Step Cause Remedy
1
Document rear actuator catching
on some position.
Correct catching of the document rear
actuator.
2 Document rear sensor failure Replace the document rear sensor.
3 Main PCB failure Replace the main PCB ASSY.
Cover is Open
Close the ADF cover.
<User Check>
• Close the ADF cover.
Step Cause Remedy
1
ADF cover open sensor arm
catching on some position.
Correct catching of the ADF cover open
sensor.
2
ADF cover is changed in shape or
cracked.
Replace the ADF cover.
3 ADF cover open sensor failure Replace the ADF cover open sensor.
4 ADF relay PCB failure Replace the ADF relay PCB ASSY.
5 Main PCB failure Replace the main PCB ASSY.

Brother MFC-8380DN Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Scan to	e-mail, FTP, OCR, USB
Input color depth	48 bit
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
Maximum number of copies	99 copies
N-in-1 copy function (N=)	4, 9, 16, 25
Copy speed (black, normal quality, A4)	30 cpm
Faxing	Mono faxing
Fax memory	500 pages
Modem speed	33.6 Kbit/s
Total input capacity	500 sheets
Total output capacity	150 sheets
Multi-Purpose tray input capacity	50 sheets
Auto document feeder (ADF) input capacity	20 sheets
Internal memory	64 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	56 dB
Display	LCD
Market positioning	Home & office
Custom media sizes	(69.8 - 216) x (116 - 406.4) mm
Dimensions (WxDxH)	531 x 451 x 475 mm
Networking features	10/100 Base-TX
All-in-one functions	Copy, Fax, Scan
Maximum internal memory	0.576 GB
Color all-in-one functions	scan, n
Compatible operating systems	Linux, Windows 2000, XP/2003, Vista, XP, Mac OS X 10.3.9
Maximum print size	216 x 297 mm
Media weight (tray 1)	60 - 105 gsm
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
Non-ISO print media sizes	Executive
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Supported network protocols (IPv4)	IPv4, IPv6
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	85 W
Power consumption (PowerSave)	19 W
Power consumption (average operating)	680 W
Package weight	21100 g
