■ CIS model
9.12.2 NCU PCB ASSY
(1) Disconnect the Connector of the NCU harness from the Main PCB.
Fig. 5-184
Note:
• In the case of the CCD model, refer to "9.12.1 NCU PCB ASSY".
Main PCB
Main PCB
NCU harness
<Left side>
