Brother MFC-8380DN Service Manual

1-15
Confidential
<Wireless network>
Specifications are subject to change without notice.
Network node type NC-7600w
Operating system
support
Windows Vista
®
, Windows Server
®
2003 x64 Edition
*2
, Windows
®
XP
Professional x64 Edition
*1
, Windows
®
2003, Windows
®
XP, Windows
®
2000, Mac OS
®
X 10.3.9 or greater
Protocol support TCP/IP: IPv4 ARP, RARP, BOOTP, DHCP, APIPA (Auto IP),
WINS/NetBIOS name resolution, DNS Resolver,
mDNS, LLMNR responder, LPR/LPD, Custom Raw
Port/Port9100, IPP/IPPS, FTP Server, TELNET
Server, HTTP/HTTPS server, TFTP client and
server, SMTP Client, APOP, POP before SMTP,
SMTP-AUTH, SNMP v1/v2c/v3, ICMP, LLTD
responder, Web Services Print, CIFS Client, SNTP
TCP/IP: IPv6
*2
NDP, RA, DNS resolver, mDNS, LLMNR responder,
LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS,
FTP Server, TELNET Server, HTTP/HTTPS server,
TFTP client and server, SMTP Client, APOP, POP
before SMTP, SMTP-AUTH, SNMPv1/v2c/v3,
ICMPv6, LLTD responder, Web Services Print, CIFS
Client, SNTP
Network type IEEE 802.11b/g wireless
Frequency 2412 - 2472 MHz
RF channel US/Canada 1 - 11
Europe/Oceania 1 - 13
Japan 1 - 14
Communication
mode
Infrastructure, Ad-hoc 802.11 b
Data rate 802.11 b 11/5.5/2/1 Mbps
802.11 g 54/48/36/24/18/12/11/9/6 Mbps
Link distance 70 m (233 ft.) at lowest data rate (The distance rate will vary upon
environment and other equipment location.)
Network security WEP 64/128, WPA-PSK (TKIP/AES), WPA2-PSK (AES), LEAP, EAP-
FAST
Management utility BRAdmin Professional 3
*3
for Windows
(Brother original Windows utility for printer and server management)
Web BRAdmin
*3
for Windows
(Server based management utility / Windows IIs (4.0/5.0) mode only)
Web Based Management
BRAdmin Light for Windows and Macintosh
(Printer and print server management through web browser)
recommend Microsoft Internet Explorer 6.0 (or greater), Fire fox 1.0 (or
greater) for Windows
Safar: 1.2 (or greater) for Macintosh
*1
A wireless network connection is supported only between the Brother printer and an
access point for PC's running Windows Server
®
2003 x64 Edition and Windows
®
XP
Professional x64 Edition.
*2
If you want to use the IPv6 protocol, visit http://solutions.brother.com for more information.
*3
BRAdmin Professional 3 and Web BRAdmin are available as a download from
http://solutions.brother.com
.

Brother MFC-8380DN Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Scan to	e-mail, FTP, OCR, USB
Input color depth	48 bit
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
Maximum number of copies	99 copies
N-in-1 copy function (N=)	4, 9, 16, 25
Copy speed (black, normal quality, A4)	30 cpm
Faxing	Mono faxing
Fax memory	500 pages
Modem speed	33.6 Kbit/s
Total input capacity	500 sheets
Total output capacity	150 sheets
Multi-Purpose tray input capacity	50 sheets
Auto document feeder (ADF) input capacity	20 sheets
Internal memory	64 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	56 dB
Display	LCD
Market positioning	Home & office
Custom media sizes	(69.8 - 216) x (116 - 406.4) mm
Dimensions (WxDxH)	531 x 451 x 475 mm
Networking features	10/100 Base-TX
All-in-one functions	Copy, Fax, Scan
Maximum internal memory	0.576 GB
Color all-in-one functions	scan, n
Compatible operating systems	Linux, Windows 2000, XP/2003, Vista, XP, Mac OS X 10.3.9
Maximum print size	216 x 297 mm
Media weight (tray 1)	60 - 105 gsm
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
Non-ISO print media sizes	Executive
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Supported network protocols (IPv4)	IPv4, IPv6
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	85 W
Power consumption (PowerSave)	19 W
Power consumption (average operating)	680 W
Package weight	21100 g
