Brother MFC-8380DN Service Manual

7-44
Confidential
4.24 Counter Reset After Replacing the Fuser Unit,Laser Unit and Paper
Feed Kit (Function code 88)
<Function>
The number of replacement is increased by one, and the warning indication “Replace ***” is
cleared, with implementing this operation after replacing the fuser unit, laser unit and paper
feed Kit (MP, T1, T2).
<Operating Procedure>
(1) Press the [8] and [8] keys in this order in the initial stage of the maintenance mode.
(2) The LCD shows the “Reset Laser Unit”.
(3) Press the [ ] or [ ] button to select the item you want to reset. The LCD shows.
“Reset-Fuser Unit”
“Reset-Laser Unit”
“Reset PF-KIT MP”
“Reset PF-KIT T1”
“Reset PF-KIT T2”
(4) Press the [OK] or [Start] button, then “ *** OK?” will appear on the LCD.
(5) OK: Press the [Start] button to reset the counter of the selected part and returns the
operating procedure (2) mode.
NG: Press the [ ] button to return the operating procedure (2) mode. Then select again
the part which you want to reset by using [ ] button or [ ] button.
4.25 Maintenance Mode Finish (Function code 99)
<Function>
Finish the maintenance mode.
<Operating Procedure>
(1) Press the [9] key twice in the initial stage of the maintenance mode.
(2) The maintenance mode is finished, and the machine returns to the standby status.

Brother MFC-8380DN Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Scan to	e-mail, FTP, OCR, USB
Input color depth	48 bit
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
Maximum number of copies	99 copies
N-in-1 copy function (N=)	4, 9, 16, 25
Copy speed (black, normal quality, A4)	30 cpm
Faxing	Mono faxing
Fax memory	500 pages
Modem speed	33.6 Kbit/s
Total input capacity	500 sheets
Total output capacity	150 sheets
Multi-Purpose tray input capacity	50 sheets
Auto document feeder (ADF) input capacity	20 sheets
Internal memory	64 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	56 dB
Display	LCD
Market positioning	Home & office
Custom media sizes	(69.8 - 216) x (116 - 406.4) mm
Dimensions (WxDxH)	531 x 451 x 475 mm
Networking features	10/100 Base-TX
All-in-one functions	Copy, Fax, Scan
Maximum internal memory	0.576 GB
Color all-in-one functions	scan, n
Compatible operating systems	Linux, Windows 2000, XP/2003, Vista, XP, Mac OS X 10.3.9
Maximum print size	216 x 297 mm
Media weight (tray 1)	60 - 105 gsm
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
Non-ISO print media sizes	Executive
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Supported network protocols (IPv4)	IPv4, IPv6
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	85 W
Power consumption (PowerSave)	19 W
Power consumption (average operating)	680 W
Package weight	21100 g
