Brother MFC-8380DN Service Manual

7-36
Confidential
4.17 Paper Feeding and Ejecting Test (Function code 67)
<Function>
This function allows you to check that a sheet of paper is fed and ejected correctly by printing
the grid pattern on a page, whose interval is 1cm.
<Operating Procedure>
(1) Press the [6] and [7] keys in this order in the initial stage of the maintenance mode.
(2) The “SLECT A4” will appear on the LCD. Select the paper size by using [ ] [ ] button.
Press the [OK] button.
(3) The “SELECT: TRAY1” will appear on the LCD. Select the paper tray by using [ ] [ ]
button. Press the [OK] button.
(4) The “PAPER DEED TEST” will appear on the LCD. The test printing is started, and the
grid pattern is printed.
(5) Press the [Stop/Exit] button so that machine stops printing. Then the machine returns to
the initial stage of the maintenance mode.
4.18 EEPROM Customizing (Function code 74)
<Function>
This function allows you to customize the EEPROM according to language, function settings,
and worker switch settings.
<Operating Procedure>
(1) Press the [7] and [4] keys in this order in the initial stage of the maintenance mode.
The current customizing code appears.
(2) Enter the desired customizing code (e.g., MFC-8890DW (US): 0401). The newly entered
code appears.
To enter letters “A” through “F”, press the [1] through [6] keys while holding down the [#]
key respectively.
(3) Press the [Start] button.
The machine saves the setting and displays the “PARAMETER INIT” on the LCD. The
machine beeps for one second and returns to the initial stage of the maintenance mode.
If you press the [Stop/Exit] button or no buttons are pressed for one minute in the above
procedure, the machine stops the procedure, beeps for one second and returns to the
initial stage of the maintenance mode.
The modification of the setting data is not saved in this case.
Note:
• In the case that the front cover is opened, or that there is no paper in the tray during
test printing, the test printing is stopped.
Note:
• If you replace the main PCB, be sure to carry out this procedure.
Note:
• The machine does not work properly when an incorrect code is entered.

Brother MFC-8380DN Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Scan to	e-mail, FTP, OCR, USB
Input color depth	48 bit
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
Maximum number of copies	99 copies
N-in-1 copy function (N=)	4, 9, 16, 25
Copy speed (black, normal quality, A4)	30 cpm
Faxing	Mono faxing
Fax memory	500 pages
Modem speed	33.6 Kbit/s
Total input capacity	500 sheets
Total output capacity	150 sheets
Multi-Purpose tray input capacity	50 sheets
Auto document feeder (ADF) input capacity	20 sheets
Internal memory	64 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	56 dB
Display	LCD
Market positioning	Home & office
Custom media sizes	(69.8 - 216) x (116 - 406.4) mm
Dimensions (WxDxH)	531 x 451 x 475 mm
Networking features	10/100 Base-TX
All-in-one functions	Copy, Fax, Scan
Maximum internal memory	0.576 GB
Color all-in-one functions	scan, n
Compatible operating systems	Linux, Windows 2000, XP/2003, Vista, XP, Mac OS X 10.3.9
Maximum print size	216 x 297 mm
Media weight (tray 1)	60 - 105 gsm
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
Non-ISO print media sizes	Executive
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Supported network protocols (IPv4)	IPv4, IPv6
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	85 W
Power consumption (PowerSave)	19 W
Power consumption (average operating)	680 W
Package weight	21100 g
