Brother MFC-8380DN Service Manual

1-31
Confidential
2.10 Fax
Model
MFC
8480DN
MFC
8880DN
MFC
8890DW
MFC
8370DN
MFC
8380DN
Modem Speed 33.600 bps 33.600 bps (Fax)
Transmission Speed Approx. 2 sec.
(Brother#1Chart Std resolution, JBIG)
ITU-T Group Super G3
Coding Method MH / MR / MMR / JBIG
Color FAX
No
Fax/Tel Switch Yes
Superfine Yes (TX & RX)
Grayscale 8 bit / 256
Contrast Yes (Auto/Light/Dark)
Smoothing
No
Dual Access Yes
Remote Activate Yes
Station ID Yes (20 digits / 20 characters)
Remote Maintenance
No
Remote Access Yes
Fax Retrieval Yes
Paging Yes (U.S.A. / Canada Only)
No
Internet FAX
(ITU T.37 simple mode)
No Yes No
Sending Delayed Timer Yes (up to 50)
Polled
Sending
Yes (EUR Secure Polling)
Multi
Transmission
No
Multi
Resolution
Transmission
No
Next-Fax
Reservation
No
Call
Reservation
Over Auto/
Manual TX
No
Batch
Transmission
Yes
Quick-Scan
(Memory
transmission)
Approx. 2 sec./page (A4 standard)

Brother MFC-8380DN Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Scan to	e-mail, FTP, OCR, USB
Input color depth	48 bit
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
Maximum number of copies	99 copies
N-in-1 copy function (N=)	4, 9, 16, 25
Copy speed (black, normal quality, A4)	30 cpm
Faxing	Mono faxing
Fax memory	500 pages
Modem speed	33.6 Kbit/s
Total input capacity	500 sheets
Total output capacity	150 sheets
Multi-Purpose tray input capacity	50 sheets
Auto document feeder (ADF) input capacity	20 sheets
Internal memory	64 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	56 dB
Display	LCD
Market positioning	Home & office
Custom media sizes	(69.8 - 216) x (116 - 406.4) mm
Dimensions (WxDxH)	531 x 451 x 475 mm
Networking features	10/100 Base-TX
All-in-one functions	Copy, Fax, Scan
Maximum internal memory	0.576 GB
Color all-in-one functions	scan, n
Compatible operating systems	Linux, Windows 2000, XP/2003, Vista, XP, Mac OS X 10.3.9
Maximum print size	216 x 297 mm
Media weight (tray 1)	60 - 105 gsm
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
Non-ISO print media sizes	Executive
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Supported network protocols (IPv4)	IPv4, IPv6
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	85 W
Power consumption (PowerSave)	19 W
Power consumption (average operating)	680 W
Package weight	21100 g
