Brother MFC-8380DN Service Manual

3-63
Confidential
6. SOFTWARE SETTING PROBLEMS
The machine may not print the data correctly if there are incorrect software settings.
<User Check>
- Check that the parallel cable, USB cable and the network cable is not damaged or
broken.
- Check that the correct machine is selected if you have an interface switching device.
- Check the descriptions on the software setting in the user’s guide.
- Try resetting the factory settings. (Refer to Users guide.)
Step Cause Check
Result Remedy
1
Failure inside the
machine
Does the machine print
“Printer Settings” ?
("4.21 Display of the
Machine’s Log
Information (Function
code 80)" in Chapter 7.)
No
Identify the error type, and
then refer to the specified
section of this chapter.
2
Machine
connection
For Macintosh, has the
product ID been
verified?
No
Verify the product
ID.Product ID:
DCP8070D 021Bh
DCP8080DN 0218h
DCP8085DN 021Fh
MFC8370DN 021Ah
MFC8380DN 0219h
MFC8480DN 0217h
MFC8880DN 0216h
MFC8890DW 0215h
3
USB host relay
PCB failure
Is the problem solved
after replacing the USB
host relay PCB ASSY?
Yes
Replace the USB host
relay PCB ASSY.
4
Main PCB failure Is the problem solved
after replacing the main
PCB ASSY?
Yes
Replace the main PCB
ASSY.

Brother MFC-8380DN Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Scan to	e-mail, FTP, OCR, USB
Input color depth	48 bit
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
Maximum number of copies	99 copies
N-in-1 copy function (N=)	4, 9, 16, 25
Copy speed (black, normal quality, A4)	30 cpm
Faxing	Mono faxing
Fax memory	500 pages
Modem speed	33.6 Kbit/s
Total input capacity	500 sheets
Total output capacity	150 sheets
Multi-Purpose tray input capacity	50 sheets
Auto document feeder (ADF) input capacity	20 sheets
Internal memory	64 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	56 dB
Display	LCD
Market positioning	Home & office
Custom media sizes	(69.8 - 216) x (116 - 406.4) mm
Dimensions (WxDxH)	531 x 451 x 475 mm
Networking features	10/100 Base-TX
All-in-one functions	Copy, Fax, Scan
Maximum internal memory	0.576 GB
Color all-in-one functions	scan, n
Compatible operating systems	Linux, Windows 2000, XP/2003, Vista, XP, Mac OS X 10.3.9
Maximum print size	216 x 297 mm
Media weight (tray 1)	60 - 105 gsm
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
Non-ISO print media sizes	Executive
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Supported network protocols (IPv4)	IPv4, IPv6
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	85 W
Power consumption (PowerSave)	19 W
Power consumption (average operating)	680 W
Package weight	21100 g
