Brother MFC-8380DN Service Manual

5-2
Confidential
2. TRANSFERRING RECEIVED FAX DATA
When the machine at the user site requires to be repaired, unplugging the power cord from
the wall socket for sending the machine for repair will lose received FAX data if unprinted and
left in the machine.
To prevent such data loss, the service personnel should instruct end users (e.g., by
telephone) to transfer data to another facsimile machine using the procedure below.
■ Operating Procedure
(1) Connect the machine to be repaired (that has received data in the memory) to the
telephone line.
(2) Switch the machine on.
(3) Press the [Menu], [Start], [Menu] and [ ] buttons in this order.
The "MAINTENANCE 06" appears on the LCD.
(4) Call up the "MAINTENANCE 53" using the [ ] and [ ] buttons and press the [OK]
button.
The "FAX TRANSFER" appears on the LCD.
(5) To check the number of received files
, press the [1] key.
The "1.NO. OF JOBS" appears on the LCD.
Press the [OK] button, and the number of received files appears, just as "NO. OF. JOBS:
10."
Press the [Stop/Exit] button, and the “FAX TRANSFER” appears on the LCD.
(6) To transfer the activity report only
, press the [2] key.
The "2.ACTIVITY" appears.
To transfer received files together with the activity report
, press the [3] key.
The "3.DOCUMENTS" appears. Note that if there is no received file, the "NO
DOCUMENTS" appears.
To transfer the communication list for the latest communication
, press the [4] key.
The "4.COM.LIST (NEW)" appears.
To transfer the communication list for last three errors
, press the [5] key.
The "5.COM.LIST (ERR3)" appears.
Note:
• DCP models do not have this function.
• The number of files that can be transferred at a time is 99. To transfer 100 files or more,
carry out the following procedure more than one time.
TIP:
• If there are both color and monochrome data in a file to be transferred, the monochrome
data will be transferred first. If the receiver machine does not support the color function,
the sender machine cannot transfer color data, resulting in an error.

Brother MFC-8380DN Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Scan to	e-mail, FTP, OCR, USB
Input color depth	48 bit
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
Maximum number of copies	99 copies
N-in-1 copy function (N=)	4, 9, 16, 25
Copy speed (black, normal quality, A4)	30 cpm
Faxing	Mono faxing
Fax memory	500 pages
Modem speed	33.6 Kbit/s
Total input capacity	500 sheets
Total output capacity	150 sheets
Multi-Purpose tray input capacity	50 sheets
Auto document feeder (ADF) input capacity	20 sheets
Internal memory	64 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	56 dB
Display	LCD
Market positioning	Home & office
Custom media sizes	(69.8 - 216) x (116 - 406.4) mm
Dimensions (WxDxH)	531 x 451 x 475 mm
Networking features	10/100 Base-TX
All-in-one functions	Copy, Fax, Scan
Maximum internal memory	0.576 GB
Color all-in-one functions	scan, n
Compatible operating systems	Linux, Windows 2000, XP/2003, Vista, XP, Mac OS X 10.3.9
Maximum print size	216 x 297 mm
Media weight (tray 1)	60 - 105 gsm
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
Non-ISO print media sizes	Executive
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Supported network protocols (IPv4)	IPv4, IPv6
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	85 W
Power consumption (PowerSave)	19 W
Power consumption (average operating)	680 W
Package weight	21100 g
