9.11.9 Scanner Dress Cover L/R
(1) Remove the two bind B M4x12 Taptite screws, and remove the Scanner dress cover L/R
from the Scanner base ASSY.
Fig. 5-179
Scanner dress cover L
Scanner base ASSY
Scanner dress cover R
Taptite bind B M4x12
