Brother MFC-8380DN Service Manual

5-6
Confidential
4. SCREW TORQUE LIST
Location of screw Screw type Q’ty
Tightening
torque
N · m (kgf · cm)
CCD
model
CIS
model
FU harness cover 1 Taptite pan B M4x20 1 0.7±0.1 (7±1)
Fuser unit Taptite pan B M4x20 1 0.7±0.1 (7±1)
Process cover stopper Taptite cup B M4x10 1 0.5±0.1 (5±1)
Emblem cover Taptite cup B M3x10 2 0.5±0.1 (5±1)
Side cover L Taptite bind B M4x12 2 0.7±0.1 (7±1)
Shield cover ASSY
(FG harness)
Taptite cup S M3x6 SR 4 0.75±0.1 (7.5±1)
CCD
model
ADF FG harness Taptite cup S M3x6 1 0.7±0.05 (7±0.5)
Hinge base R Taptite cup B M3x10 2 0.8±0.1 (8±1)
Hinge ASSY L
Taptite cup B M3x10 2 0.5±0.1 (5±1)
Taptite cup S M3x12 1 0.7±0.1 (7±1)
ADF side cover F
Taptite cup B M3x10 1 0.5±0.1 (5±1)
Taptite cup S M3x8 1 0.5±0.1 (5±1)
ADF side cover R
Taptite cup B M3x10 1 0.5±0.1 (5±1)
Taptite cup S M3x8 1 0.7±0.05 (7±0.5)
ADF chute ASSY Taptite cup B M3x10 5 0.5±0.1 (5±1)
SX Chute Taptite cup S M3x8 2 0.5±0.1 (5±1)
Exit chute cover ASSY Taptite cup B M3x10 4 0.5±0.1 (5±1)
ADF motor
Screw, pan (S/P
washer) M3X6
2
0.7±0.1 (7±1)
Motor frame ASSY Taptite cup S M3x8 3 0.7±0.05 (7±0.5)
Switch back solenoid ASSY Taptite cup S M3x8 1 0.7±0.05 (7±0.5)
PF solenoid ASSY Taptite cup S M3x8 1 0.7±0.05 (7±0.5)
ADF relay PCB Taptite cup S M3x8 1 0.7±0.05 (7±0.5)
Paper feed plate Taptite cup S M3x8 2 0.7±0.05 (7±0.5)
Paper feed chute ASSY Taptite cup S M3x8 2 0.7±0.05 (7±0.5)
Separation rubber Taptite B M3x6 1 0.4±0.05 (4±0.5)
Drive frame sub ASSY DX Taptite cup B M3x10 3 0.5±0.1 (5±1)
Front frame Taptite cup B M3x10 3 0.5±0.1 (5±1)
Upper main chute ASSY Taptite cup B M3x10 4 0.5±0.1 (5±1)
Rear sensor cover Taptite cup B M3x10 2 0.5±0.1 (5±1)
LF spring Taptite cup B M3x10 2 0.5±0.1 (5±1)
CIS
model
FG harness Taptite cup S M3x6 SR 2 0.75±0.1 (7.5±1)
Shield cover ASSY Taptite cup S M3x6 SR 2 0.75±0.1 (7.5±1)
ADF FG harness Taptite cup S M3x6 1 0.7±0.05 (7±0.5)
ADF unit Taptite bind B M4x12 2 0.8±0.1 (8±1)
Hinge ASSY Taptite cup S M3x10 3 0.9±0.05 (9±0.5)
ADF gear cover Taptite cup B M3x10 1 0.5±0.1 (5±1)

Brother MFC-8380DN Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Scan to	e-mail, FTP, OCR, USB
Input color depth	48 bit
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
Maximum number of copies	99 copies
N-in-1 copy function (N=)	4, 9, 16, 25
Copy speed (black, normal quality, A4)	30 cpm
Faxing	Mono faxing
Fax memory	500 pages
Modem speed	33.6 Kbit/s
Total input capacity	500 sheets
Total output capacity	150 sheets
Multi-Purpose tray input capacity	50 sheets
Auto document feeder (ADF) input capacity	20 sheets
Internal memory	64 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	56 dB
Display	LCD
Market positioning	Home & office
Custom media sizes	(69.8 - 216) x (116 - 406.4) mm
Dimensions (WxDxH)	531 x 451 x 475 mm
Networking features	10/100 Base-TX
All-in-one functions	Copy, Fax, Scan
Maximum internal memory	0.576 GB
Color all-in-one functions	scan, n
Compatible operating systems	Linux, Windows 2000, XP/2003, Vista, XP, Mac OS X 10.3.9
Maximum print size	216 x 297 mm
Media weight (tray 1)	60 - 105 gsm
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
Non-ISO print media sizes	Executive
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Supported network protocols (IPv4)	IPv4, IPv6
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	85 W
Power consumption (PowerSave)	19 W
Power consumption (average operating)	680 W
Package weight	21100 g
