5-160
Confidential
(2) Remove the four bind B M4x12 Taptite screws, and remove the NCU cover from the
Joint cover ASSY.
Fig. 5-185
Taptite bind B M4x12
Taptite bind B M4x12
NCU cover
Joint cover ASSY
