Brother MFC-8380DN Service Manual

3-69
Confidential
(11) General communications-related
(12) Transmission in V. 34 mode
Code 1 Code 2 Causes
B0 02 Unable to receive the next-page data.
B0 03
Unable to receive polling even during turn-around
transmission due to call reservation.
B0 04 PC interface error.
BF 01
Communication canceled by pressing the Stop/Exit
button before establishment of FAX communication*.
BF 02
Communication canceled by pressing the Stop/Exit
button after establishment of FAX communication*.
BF 03
Transmission canceled due to a scanning error caused
by no document or document feed problem in ADF
scanning in real time transmission.
* Establishment of FAX communication:
FAX communication is established when the calling station receives a DIS
(reception capability) signal from the called station and the called station receives a
NSS or DCS (communications test) signal from the calling station.
Code 1 Code 2 Causes
C0 01 No common modulation mode or failed to poll.
C0 02 Unable to detect JM.
C0 03 Unable to detect CM.
C0 04 Unable to detect CJ.
C0 10 Cannot finish V. 34 negotiation or training.
C0 11
Modem error is detected during V. 34 negotiation or
training. (For modem error details, refer to the table
given on the next page.)
C0 20
Modem error is detected during sending of commands.
(For modem error details, refer to the table given on the
next page.)
C0 21
Modem error is detected during receiving of commands.
(For modem error details, refer to the table given on the
next page.)
C0 22 Control channel connection time-out.
C0 30
Modem error is detected during sending of video
signals. (For modem error details, refer to the table
given on the next page.)
C0 31
Modem error is detected during receiving of video
signals. (For modem error details, refer to the table
given on the next page.)

Brother MFC-8380DN Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Scan to	e-mail, FTP, OCR, USB
Input color depth	48 bit
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
Maximum number of copies	99 copies
N-in-1 copy function (N=)	4, 9, 16, 25
Copy speed (black, normal quality, A4)	30 cpm
Faxing	Mono faxing
Fax memory	500 pages
Modem speed	33.6 Kbit/s
Total input capacity	500 sheets
Total output capacity	150 sheets
Multi-Purpose tray input capacity	50 sheets
Auto document feeder (ADF) input capacity	20 sheets
Internal memory	64 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	56 dB
Display	LCD
Market positioning	Home & office
Custom media sizes	(69.8 - 216) x (116 - 406.4) mm
Dimensions (WxDxH)	531 x 451 x 475 mm
Networking features	10/100 Base-TX
All-in-one functions	Copy, Fax, Scan
Maximum internal memory	0.576 GB
Color all-in-one functions	scan, n
Compatible operating systems	Linux, Windows 2000, XP/2003, Vista, XP, Mac OS X 10.3.9
Maximum print size	216 x 297 mm
Media weight (tray 1)	60 - 105 gsm
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
Non-ISO print media sizes	Executive
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Supported network protocols (IPv4)	IPv4, IPv6
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	85 W
Power consumption (PowerSave)	19 W
Power consumption (average operating)	680 W
Package weight	21100 g
