Brother MFC-8380DN Service Manual

5-15
Confidential
■ Gear name
1 LM5016001 EJECTOR GEAR 16 15 LM5065001 MP GEAR 55/60 SECTOR
2 LJ7365001 IDLE GEAR 16B 16 LM5104001 GEAR 17 (white)
3 LM5016001 EJECTOR GEAR 16 17 LM5057001 FEEDER GEAR 48
4 LM5013001 EJECT GEAR 28 SECTOR 18 LM5050001 DX GEAR 27/68 L
5 LM5019001 EJECTOR GEAR 22 19 LM5460001 P/P DIFFERENTIAL
6 LM5048001 FUSER GEAR 39R H/R DRIVE 20 LM5025001 P/P GEAR 17 CENTER
7 LM5042001 FUSER GEAR 17/63R PENDULUM 21 LM5026001 P/P GEAR 32CARRIER
8 LM5052001 REGISTER GEAR 21 CENTER 22 LM5027001 P/P GEAR 15 PLANETARY
9 LM5053001 REGISTER GEAR 48 CARRIER 23 LM5028001 P/P GEAR 147/37 INTERNAL
10 LM5055001 REGISTER GEAR 159/43 INTERNAL 24 LM5023001 P/P GEAR 29 CLUTCH CAM
11 LM5054001 REGISTOR GEAR 19 PLANETARY 25 LM5070001 T1 GEAR 31/47
12 LM5101001 GEAR 23 26 LU7020001 T1 GEAR 50/45 SECTOR
13 LM5461001 REGISTER DIFFERENTIAL 27 LM5103001 GEAR 20
14 LM5056001 FEEDER GEAR 21/31 PENDULUM 28 LM5102001 GEAR 17 (black)

Brother MFC-8380DN Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Scan to	e-mail, FTP, OCR, USB
Input color depth	48 bit
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
Maximum number of copies	99 copies
N-in-1 copy function (N=)	4, 9, 16, 25
Copy speed (black, normal quality, A4)	30 cpm
Faxing	Mono faxing
Fax memory	500 pages
Modem speed	33.6 Kbit/s
Total input capacity	500 sheets
Total output capacity	150 sheets
Multi-Purpose tray input capacity	50 sheets
Auto document feeder (ADF) input capacity	20 sheets
Internal memory	64 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	56 dB
Display	LCD
Market positioning	Home & office
Custom media sizes	(69.8 - 216) x (116 - 406.4) mm
Dimensions (WxDxH)	531 x 451 x 475 mm
Networking features	10/100 Base-TX
All-in-one functions	Copy, Fax, Scan
Maximum internal memory	0.576 GB
Color all-in-one functions	scan, n
Compatible operating systems	Linux, Windows 2000, XP/2003, Vista, XP, Mac OS X 10.3.9
Maximum print size	216 x 297 mm
Media weight (tray 1)	60 - 105 gsm
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
Non-ISO print media sizes	Executive
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Supported network protocols (IPv4)	IPv4, IPv6
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	85 W
Power consumption (PowerSave)	19 W
Power consumption (average operating)	680 W
Package weight	21100 g
