5-27
Confidential
19
ADF unit (CIS model)
Hole
ADF Relay PCB
ADF unit
ADF harness
ADF motor harness
Document eject sensor harness
ADF motor harness
ADF motor
FG harness
ADF Relay harness
ADF Relay harness
Main PCB
Drive PCB
Document cover sensor harness
Document cover
sensor harness
Driver PCB harness
Scanner unit
ADF FG harness
