Brother MFC-8380DN Service Manual

App. 1-29
Confidential
<WSW26> (Function setting 4)
• Selector 3: Dialing during document reading into the temporary memory in in-
memory message transmission
If this selector is set to "0," the machine waits for document reading into the memory to
complete and then starts dialing. This enables the machine to list the total number of
pages in the header of the facsimile message.
• Selectors 4 and 5:No. of CNG cycles to be detected (when the line is connected via
the external telephone except in the external TAD mode or via the
built-in telephone)
The machine interprets a CNG as an effective signal if it detects the CNG by the number of
cycles specified by these selectors when the line is connected via the external telephone
except in the external TAD mode or via the built-in telephone.
Selector No. Function Setting and Specifications
1
2
Not used.
3
Dialing during document reading
into the temporary memory in in-
memory message transmission
0: Disable 1: Enable
4
5
No. of CNG cycles to be detected
(when the line is connected via
the external telephone except in
the external TAD mode or via the
built-in telephone)
In the case of Selector 3=0 in WSW54.
No. 4 5
00: 0.5 (A)
01: 1 (B)
10: 1.5 (C)
11: 2 (D)
In the case of Selector 3=1 in WSW54.
No. 4 5
00: 2.5 (A)
01: 3 (B)
10: 3.5 (C)
11: 4 (D)
6
7
No. of CNG cycles to be detected
(when the line is connected via
the external telephone in the
external TAD mode, via the built-
in telephone in the TAD mode, or
via the machine in the automatic
reception of the F/T mode)
In the case of Selector 6=0 in WSW58.
No. 6 7
00: 0.5 (A)
01: 1 (B)
10: 1.5 (C)
11: 2 (D)
In the case of Selector 6=1 in WSW58.
No. 6 7
00: 2.5 (A)
01: 3 (B)
10: 3.5 (C)
11: 4 (D)
8 Not used.

Brother MFC-8380DN Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Scan to	e-mail, FTP, OCR, USB
Input color depth	48 bit
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
Maximum number of copies	99 copies
N-in-1 copy function (N=)	4, 9, 16, 25
Copy speed (black, normal quality, A4)	30 cpm
Faxing	Mono faxing
Fax memory	500 pages
Modem speed	33.6 Kbit/s
Total input capacity	500 sheets
Total output capacity	150 sheets
Multi-Purpose tray input capacity	50 sheets
Auto document feeder (ADF) input capacity	20 sheets
Internal memory	64 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	56 dB
Display	LCD
Market positioning	Home & office
Custom media sizes	(69.8 - 216) x (116 - 406.4) mm
Dimensions (WxDxH)	531 x 451 x 475 mm
Networking features	10/100 Base-TX
All-in-one functions	Copy, Fax, Scan
Maximum internal memory	0.576 GB
Color all-in-one functions	scan, n
Compatible operating systems	Linux, Windows 2000, XP/2003, Vista, XP, Mac OS X 10.3.9
Maximum print size	216 x 297 mm
Media weight (tray 1)	60 - 105 gsm
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
Non-ISO print media sizes	Executive
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Supported network protocols (IPv4)	IPv4, IPv6
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	85 W
Power consumption (PowerSave)	19 W
Power consumption (average operating)	680 W
Package weight	21100 g
