<WSW32> (Function setting 10)
• Selectors 5 and 6: Default resolution
These selectors set the default resolution which applies when the machine is turned on or
completes a transaction.
• Selectors 7 and 8: Default contrast
These selectors set the default contrast which applies when the machine is turned on or
completes a transaction.
<WSW33> (Function setting 11)
Selector No. Function Setting and Specifications
1
I
4
Not used.
5
6
Default resolution when FAX
scanning
No. 5 6
0 0: Standard
01: Fine
1 0: Super fine
11: Photo
7
8
Default contrast when FAX
scanning
No. 7 8
0 0: Automatic
0 1: Automatic
1 0: Super light
1 1: Super dark
Selector No. Function Setting and Specifications
1
I
3
Detection threshold level of "no
tone" during recording of ICM
(Not used.)
4
5
FAX receiving speed to be kept
within the transmission speed
limit to the PC (Not used.)
6
Report output of polled
transmission requests
0: Yes 1: No
7
8
Comfortable noise level
(Not used.)

Brother MFC-8380DN Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Scan to	e-mail, FTP, OCR, USB
Input color depth	48 bit
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
Maximum number of copies	99 copies
N-in-1 copy function (N=)	4, 9, 16, 25
Copy speed (black, normal quality, A4)	30 cpm
Faxing	Mono faxing
Fax memory	500 pages
Modem speed	33.6 Kbit/s
Total input capacity	500 sheets
Total output capacity	150 sheets
Multi-Purpose tray input capacity	50 sheets
Auto document feeder (ADF) input capacity	20 sheets
Internal memory	64 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	56 dB
Display	LCD
Market positioning	Home & office
Custom media sizes	(69.8 - 216) x (116 - 406.4) mm
Dimensions (WxDxH)	531 x 451 x 475 mm
Networking features	10/100 Base-TX
All-in-one functions	Copy, Fax, Scan
Maximum internal memory	0.576 GB
Color all-in-one functions	scan, n
Compatible operating systems	Linux, Windows 2000, XP/2003, Vista, XP, Mac OS X 10.3.9
Maximum print size	216 x 297 mm
Media weight (tray 1)	60 - 105 gsm
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
Non-ISO print media sizes	Executive
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Supported network protocols (IPv4)	IPv4, IPv6
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	85 W
Power consumption (PowerSave)	19 W
Power consumption (average operating)	680 W
Package weight	21100 g
