Brother MFC-8380DN Service Manual

App. 1-36
Confidential
<WSW36> (Function setting 14)
*ECP (Enhanced Capabilities Port)
• Selector 1: ECP mode
The ECP mode enhances the normal bidirectional communications between the machine
and the connected PC for higher transmission speed throgh the parallel interface.
• Selector 2: Recovery from Inactive PC Interface
If the machine recognizes via the STB signal line that the connected PC is powered off
throgh the parallel interface, it will turn the PC interface outputs Low to protect the PC from
hazards that could be caused by weak electric current accidentally flown from the machine.
This selector determines whether or not the machine should recover from the inactive PC
interface to normal interfacing state upon receipt of data from the PC.
• Selector 3: PC Power-off Recognition Time
This selector sets the time length from when the machine detects the PC powered off until
it recognizes the detected state as power-off.
If selector 2 is set to "0," it is recommended that selector 3 be set to "1"; otherwise, the
machine may mistakenly detect PC powered off.
• Selector 5: Escape from phase C
This selector determines whether or not the machine will escape from phase C when it
detects an RTC (Return to Control) in non-ECM mode or an RCP (Return to Control Partial
page) in ECM mode.
Selector No. Function Setting and Specifications
1 ECP mode* 0: ON 1: OFF
2
Recovery from Inactive PC
Interface
0: Disable 1: Enable
3 PC Power-off Recognition Time 0: Normal 1: Long
4 Not used.
5 Escape from phase C 0: Yes 1: No
6
I
8
Extension of incoming calling
signal (CI) frequency band
specified by selectors 1 through
4 on WSW14
No. 6 7 8
0 0 0: 0 (Ignored)
0 0 1: 4 (448 Hz)
0 1 0: 8 (244 Hz)
0 1 1: 12 (162 Hz)
1 0 0: 16 (122 Hz)
1 0 1: 20 (97 Hz)
1 1 0: 24 (81 Hz)
1 1 1: 28 (69 Hz)
Note:
• Selectors 2 and 3 will become operative if selectors 1 and 2 of WSW46 are set to
"monitor" the PC power ON/OFF state.

Brother MFC-8380DN Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Scan to	e-mail, FTP, OCR, USB
Input color depth	48 bit
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
Maximum number of copies	99 copies
N-in-1 copy function (N=)	4, 9, 16, 25
Copy speed (black, normal quality, A4)	30 cpm
Faxing	Mono faxing
Fax memory	500 pages
Modem speed	33.6 Kbit/s
Total input capacity	500 sheets
Total output capacity	150 sheets
Multi-Purpose tray input capacity	50 sheets
Auto document feeder (ADF) input capacity	20 sheets
Internal memory	64 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	56 dB
Display	LCD
Market positioning	Home & office
Custom media sizes	(69.8 - 216) x (116 - 406.4) mm
Dimensions (WxDxH)	531 x 451 x 475 mm
Networking features	10/100 Base-TX
All-in-one functions	Copy, Fax, Scan
Maximum internal memory	0.576 GB
Color all-in-one functions	scan, n
Compatible operating systems	Linux, Windows 2000, XP/2003, Vista, XP, Mac OS X 10.3.9
Maximum print size	216 x 297 mm
Media weight (tray 1)	60 - 105 gsm
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
Non-ISO print media sizes	Executive
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Supported network protocols (IPv4)	IPv4, IPv6
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	85 W
Power consumption (PowerSave)	19 W
Power consumption (average operating)	680 W
Package weight	21100 g
