<WSW40> (V.34 modem settings)
• Selectors 3 through 8: Masking of symbol rate(s)
These selectors allow you to limit the transmission speed range in V.34 mode by masking
the desired symbol rate(s). Transmission speeds assigned to the symbol rates are listed on
the next page. The setting made by these selectors will limit the setting made by selectors
1 through 4 on WSW39.
If selector 3 is set to "1" to mask the 3429 symbols/second when the first transmission
speed choice is 33600 bps (specified by selectors 1 through 4 of WSW39), for example,
then the allowable maximum transmission speed will be limited to 31200 bps. If selector 8
is set to "1" to mask the 2400 symbols/second when the first transmission speed choice is
33600 bps, then the allowable maximum transmission speed remains 33600 bps.
If selector 8 is set to "1" to mask the 2400 symbols/second when the first transmission
speed choice is 21600 bps (specified by selectors 1 through 4 on WSW39), then the
allowable maximum transmission speed remains 21600 bps but the minimum transmission
speed will be limited to 4800 bps.
Selector No. Function Setting and Specifications
1
2
Not used.
3
I
8
Masking of symbol rate(s)
Not masking Masking
No. 3 0 1
3429 symbols/sec
No. 4 0 1 3200 symbols/sec
No. 5 0 1 3000 symbols/sec
No. 6 0 1 2800 symbols/sec
No. 7 - - Not used.
No. 8 0 1
2400 symbols/sec
Note:
• WSW40 takes effect only when the V.34 mode is permitted (WSW19, selector 7) in
models supporting V.34 mode.

Brother MFC-8380DN Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Scan to	e-mail, FTP, OCR, USB
Input color depth	48 bit
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
Maximum number of copies	99 copies
N-in-1 copy function (N=)	4, 9, 16, 25
Copy speed (black, normal quality, A4)	30 cpm
Faxing	Mono faxing
Fax memory	500 pages
Modem speed	33.6 Kbit/s
Total input capacity	500 sheets
Total output capacity	150 sheets
Multi-Purpose tray input capacity	50 sheets
Auto document feeder (ADF) input capacity	20 sheets
Internal memory	64 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	56 dB
Display	LCD
Market positioning	Home & office
Custom media sizes	(69.8 - 216) x (116 - 406.4) mm
Dimensions (WxDxH)	531 x 451 x 475 mm
Networking features	10/100 Base-TX
All-in-one functions	Copy, Fax, Scan
Maximum internal memory	0.576 GB
Color all-in-one functions	scan, n
Compatible operating systems	Linux, Windows 2000, XP/2003, Vista, XP, Mac OS X 10.3.9
Maximum print size	216 x 297 mm
Media weight (tray 1)	60 - 105 gsm
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
Non-ISO print media sizes	Executive
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Supported network protocols (IPv4)	IPv4, IPv6
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	85 W
Power consumption (PowerSave)	19 W
Power consumption (average operating)	680 W
Package weight	21100 g
