Brother MFC-8380DN Service Manual

App. 1-55
Confidential
<WSW59> (Function setting 24)
• Selector 1: Frame length selection
This is intended to prevent the problem of a continued increase in USB ports when serial
numbers are transmitted from the MFC to a Windows Vista-based PC.
It is intended only to prevent a problem specific to Windows Vista; its default setting is "0:
USB SN enabled."
• Selector 2: Extension of the waiting time between ANSam and DIS
Setting this selector to "0" extends the waiting time between the ANSam and DIS in order
to secure the time required for switching the calling machine's echo suppressor in
transmission from a G3 to G4 FAX machine.
Selector No. Function Setting and Specifications
1
USB serial number (SN)
transmission enabled/disabled
0: USB serial number transmitted
1: USB serial number not transmitted
2
Extension of the waiting time
between ANSam and DIS
0: Enable 1: Disable
(default)
3
I
7
Checking of the specified
character code set when
displaying or printing the folder/
file names stored in memory
cards or USB flash memory
drives
No. 34567
00000 : ASC11
(default for U.S.A/
European models)
00001 : Latin1 (CP1252)
00010 : Latin2 (CP1250)
00011 : Cyrillic (CP1251)
00100 : SJIS (CP932)
(default for Japanese models)
00101 : Thai (CP874)
00110 : Korean (CP949)
00111 : Traditional Chinese (CP950)
01000 : Simplified Chinese (CP936)
(default for Chinese and
Asia & Pacific models)
01001 : Arabic (CP1256)
01010
| Reserved.
11111
8
Improvement of DTMF detection
function (to minimize the effects
of momentary power failure or
noise)
0: Disable 1: Enable
(default)

Brother MFC-8380DN Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Scan to	e-mail, FTP, OCR, USB
Input color depth	48 bit
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
Maximum number of copies	99 copies
N-in-1 copy function (N=)	4, 9, 16, 25
Copy speed (black, normal quality, A4)	30 cpm
Faxing	Mono faxing
Fax memory	500 pages
Modem speed	33.6 Kbit/s
Total input capacity	500 sheets
Total output capacity	150 sheets
Multi-Purpose tray input capacity	50 sheets
Auto document feeder (ADF) input capacity	20 sheets
Internal memory	64 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	56 dB
Display	LCD
Market positioning	Home & office
Custom media sizes	(69.8 - 216) x (116 - 406.4) mm
Dimensions (WxDxH)	531 x 451 x 475 mm
Networking features	10/100 Base-TX
All-in-one functions	Copy, Fax, Scan
Maximum internal memory	0.576 GB
Color all-in-one functions	scan, n
Compatible operating systems	Linux, Windows 2000, XP/2003, Vista, XP, Mac OS X 10.3.9
Maximum print size	216 x 297 mm
Media weight (tray 1)	60 - 105 gsm
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
Non-ISO print media sizes	Executive
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Supported network protocols (IPv4)	IPv4, IPv6
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	85 W
Power consumption (PowerSave)	19 W
Power consumption (average operating)	680 W
Package weight	21100 g
