Brother MFC-8380DN Service Manual

App. 1-57
Confidential
<WSW61> (Scanning light intensity to judge to be stable 1)
• Selectors 1 through 8: Change rate of the CCD scanning light intensity to judge to be
stable.
The light intensity of the Scanner unit is changed widely immediately after the light source
is on, that influences scanning density. Therefore, the first scanning after the light source is
off and on is started after the change rate of the Scanner light intensity is stabilized in the
definite range. These selectors set the change rate to start the scanning operation above. If
you want to start scanning immediately even if the image quality is not good, set the rate to
high.
Long / short time mode:
The selectors are divided between the long and short time modes depending on the
scanning resolution and black and white or color mode. The long time mode is selected in
color scanning at 600dpi or more, or in black and white scanning at 1200dpi. The short time
mode is selected in other scanning conditions than the above.
Selector No. Function Setting and Specifications
1
I
4
Change rate of the Scanner
scanning light intensity to judge
to be stable in the long time
mode
No. 1 2 3 4
0000: 1% (Default)
0001: 0.5%
0010: 3%
0011: 5%
0100: 10%
0101: 15%
0110: 20%
1111: 100% *
* (Scans immediately after the light
source ON)
5
I
8
Change rate of the Scanner
scanning light intensity to judge
to be stable in the short time
mode
No. 5 6 7 8
0000: 5% (Default)
0001: 1%
0010: 3%
0011: 10%
0100: 15%
0101: 20%
0110: 30%
1111: 100% *
* (Scans immediately after the light
source ON)

Brother MFC-8380DN Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Scan to	e-mail, FTP, OCR, USB
Input color depth	48 bit
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
Maximum number of copies	99 copies
N-in-1 copy function (N=)	4, 9, 16, 25
Copy speed (black, normal quality, A4)	30 cpm
Faxing	Mono faxing
Fax memory	500 pages
Modem speed	33.6 Kbit/s
Total input capacity	500 sheets
Total output capacity	150 sheets
Multi-Purpose tray input capacity	50 sheets
Auto document feeder (ADF) input capacity	20 sheets
Internal memory	64 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	56 dB
Display	LCD
Market positioning	Home & office
Custom media sizes	(69.8 - 216) x (116 - 406.4) mm
Dimensions (WxDxH)	531 x 451 x 475 mm
Networking features	10/100 Base-TX
All-in-one functions	Copy, Fax, Scan
Maximum internal memory	0.576 GB
Color all-in-one functions	scan, n
Compatible operating systems	Linux, Windows 2000, XP/2003, Vista, XP, Mac OS X 10.3.9
Maximum print size	216 x 297 mm
Media weight (tray 1)	60 - 105 gsm
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
Non-ISO print media sizes	Executive
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Supported network protocols (IPv4)	IPv4, IPv6
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	85 W
Power consumption (PowerSave)	19 W
Power consumption (average operating)	680 W
Package weight	21100 g
