Brother MFC-8380DN Service Manual

App. 1-63
Confidential
<WSW75> (Paper ejecting distance of the switch back)
• Selector 1: Adjustment for the paper feeding distance for turning the document
counter when the machine takes action duplex scanning
This selector is used to adjust the timing that the switch back roller is turned counter (the
paper feeding distance for the document which has already passed through the switch
back sensor) after scanning the first page when the machine takes action duplex scanning
from ADF by using selectors from 2 to 8.
It is available to choose the direction "+" or "-" from the standard position of the paper
feeding distance for the document which you have selected by using selectors from 2 to 8.
• Selectors 2 through 8: Paper feeding parameter for turning the document counter
when the machine takes action duplex scanning
These selectors are used to adjust the paper feeding distance from the standard position
that the timing of the switch back roller is turned counter after scanning the first page when
the machine takes action duplex scanning from ADF. The value is parameter, so it is not
actual.
Selector No. Function Setting and Specifications
1
Adjustment for the paper
feeding distance for turning the
document counter when the
machine takes action duplex
scanning
0: +
1: -
2
I
8
Paper feeding parameter for
turning the document counter
when the machine takes action
duplex scanning
No.2345678
0000000:0
0000001:1
0000010:2
|
1111111:127

Brother MFC-8380DN Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Scan to	e-mail, FTP, OCR, USB
Input color depth	48 bit
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
Maximum number of copies	99 copies
N-in-1 copy function (N=)	4, 9, 16, 25
Copy speed (black, normal quality, A4)	30 cpm
Faxing	Mono faxing
Fax memory	500 pages
Modem speed	33.6 Kbit/s
Total input capacity	500 sheets
Total output capacity	150 sheets
Multi-Purpose tray input capacity	50 sheets
Auto document feeder (ADF) input capacity	20 sheets
Internal memory	64 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	56 dB
Display	LCD
Market positioning	Home & office
Custom media sizes	(69.8 - 216) x (116 - 406.4) mm
Dimensions (WxDxH)	531 x 451 x 475 mm
Networking features	10/100 Base-TX
All-in-one functions	Copy, Fax, Scan
Maximum internal memory	0.576 GB
Color all-in-one functions	scan, n
Compatible operating systems	Linux, Windows 2000, XP/2003, Vista, XP, Mac OS X 10.3.9
Maximum print size	216 x 297 mm
Media weight (tray 1)	60 - 105 gsm
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
Non-ISO print media sizes	Executive
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Supported network protocols (IPv4)	IPv4, IPv6
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	85 W
Power consumption (PowerSave)	19 W
Power consumption (average operating)	680 W
Package weight	21100 g
