Technical Data and Installation
SMART KTF 2000 - 2.3 -
Connection example of a complete system including KTF/100HP devices, external power supply, flat cable
KTF/FLAT and SMART KTF 2000 terminal
For further details, please refer to KTF/100HP operating manual
Concerning all electrical systems, it is a suggested rule to ensure that the ground cable
(GND) is connected to the device support.
Not Used
Machine
Interface
Used for
LINK
function
To Next Page
