Spare parts and accessories
Spare part for the 8025 Batch in compact version Order code
35
6
8
12
4
7
1
2
9
10
11
13
14
Electronic board mounted in the cover with lid, with
window, foil and four screws (position 1)
425 432
Power supply board 115/230 VAC (position 2) +
mounting instruction sheet
553 168
Set including:
• two M20x1,5 cable glands (position 3)
• two neoprene flat seals (position 5) for cable gland or
screw plug
• two M20x1.5 screw plugs (position 6)
• two 2x6 mm multiway seals (position 8)
449 755
Set including:
• two M20x1,5 / NPT1/2'' reductions (mounted o-ring
seal) (position 4)
• two neoprene flat seals for plug (position 5)
• two M20x1.5 screw plugs (position 6)
551 782
Set including:
• one M20x1,5 cable gland stopper gasket (position 7)
• one multiway seal, 2x6 mm, for cable gland (position 8)
• one black EPDM seal (position 12) for the flow sensor
• one mounting instruction sheet
551 775
Housing (position 9) with snap ring and nut
425 526
Snap ring (position 10)
619 205
Nut (position 11)
619 204
Set including:
• one black EPDM seal (position 12) for the flow sensor
• one green FKM seal (position 12) for the flow sensor
552 111
Short flow sensor, Hall effect (position 13)
418 316
Long flow sensor, Hall effect (position 14)
418 324
Set with 8 FLOW foils
553 191
