Electrical installation and Wiring
230V
LN
230V
T 250 mA
56789 10
LN
230V
1
A
2
4
B
C
CURRENT
SOURCESINK
BINARY
PE PEPE
PE
DI1
DI2
DI3
DI4
DO4
ISOG
FLOW
SENSOR
L+ L- PE P- P+
NC
Iout
PULSE
DO1
Supply
12..36Vdc
Univ
Batch
(AO1)
SUPPLY
NC
COIL
PULSE
INPUT
NPN/PNP
213PE
+-
SENSOR
SUPPLY
LOAD
+5V
L+
(L+)-12V
COIL/PNP
39K
470
2.2K
SENSOR TYPE
COIL NPN/PNP
DO2
DO3
OFF ON
5
6
D
7 8
9
3
Terminal block 1
PE: factory wired shield.
Terminal block 2
• NC: not connected
• L+: V+ (red wire, factory wired)
• L-: 0V (black wire, factory wired)
• PE: protective earth, factory wired
• P-: negative transistor output (DO1) (brown wire, factory
wired)
• P+: positive transistor output (DO1) (white wire, factory
wired)
Terminal block 3 "BINARY"
• DI1 to DI4: 4 digital inputs
• DO4: transistor output
• ISOG: ISOGND, ground common to the 4 digital inputs
and the transistor output DO4.
• PE: cable shielding
Terminal block 4 "FLOW SENSOR": Wiring the remote
flow sensor. The wiring depends on the type of output
signal originating from the flow sensor: see chap. 8.9.
Terminal block 5: wiring the DO2 relay output.
Terminal block 6: wiring the DO3 relay output.
Terminal block 7
• terminal 5 not connected
• terminal 6: positive 27 V DC power supply,
available to energize an external instrument
• terminal 7: 0V (earth of the power supply
available to energize an external instrument)
• terminal 8: protective earth for the cable
shieldings
• terminal 9: negative transistor output (DO1)
• terminal 10: positive transistor output (DO1)
Terminal block 8: wiring of the 115/230 V AC
power supply
Mark
9
: time-delay fuse to protect the
115/230 V AC power supply
Selector
A
: see chap. 8.9.
Selector
B
: see Tab. 3, page 54.
Selector
C
: see chap. 8.9.
Selector
D
: see chap. 8.9.
Fig. 25 : Terminal assignment of a 8025 Batch in wall-mounted version, fed with 115/230 V AC
