Operating and functions
8.5 %
The device shows the percentage of the quantity that has been
already dosed (symbol % blinks).
→ To read the flow rate measured in the pipe, press
or
0......9
.
→ To read the total dosing quantity, press
or
0......9
once.
→ To interrupt the dosing, see Fig. 56.
→ Confirm.
BAtCH R. OK Y/N
→ Choose "OK Y" to start a new dosing.
→ Confirm.
Process level
100.4 %
When the dosing is finished:
• the display shows the reached percentage (about 100%),
• and the valves are closed.
→ To go back to the Process level in order to start a new dosing,
press
ENTER
.
Fig. 55 : Doing a dosing, in dosing mode "LOC. REP."
→ To interrupt the dosing, press
ENTER
: the valve connected to output DO2 and possibly the valve connected
to output DO3 close, the device state LED flashes at a 1 Hz-frequency and the DO4 output (if configured to
transmit the device state, see chap. 10.7.26) generates a 1 Hz-frequency.
CONtiNUE
0......9
RESEt
→ Confirm to continue the dosing.
→ Confirm to abort the dosing. The device goes back to the Process level.
10.2 %
The counting of the dosing quantity continues.
BAtCH R.
The device is ready for a new dosing.
Fig. 56 : Interrupting the dosing, in dosing mode "LOC. REP."
