Start-up
Type ME43
8 START-UP
8.1 Safety instructions
WARNING!
Riskofinjuryfromimproperoperation!
▶ Before start-up, it must be ensured that the operating personnel are aware of and fully understand the
contents of the operating instructions.
▶ Note the safety instructions and intended use.
▶ Onlytrainedandqualiedpersonnelmaystartupthedeviceorsystem.
8.2 Base settings
Sequenceofbasesettings:
1. Selecteldbusprotocol(notforPROFIBUSvariantandCC-Linkvariant)
Description see chapter “8.3Selectingeldbusprotocol”.
2. Gatewayconguration(ifnotyetavailable)
Description see chapter “8.4Congurationoftheeldbusgateway”.
3. ConguringbüSnetwork
Description see chapter “10 Setting up the büS network”.
4. Protocol settings for connecting the device to the PLC network
Description see chapter “8.5 Protocol settings for connecting the device to the PLC network”.
8.3 Selecting eldbus protocol
Selectionoftheappropriateeldbusprotocolisarequirementforcongurationofthedeviceandconnection
to the network.
The setting can be made on the display of the device or on the PC using the Bürkert Communicator PC software.
IfdevicesfeatureaPROFIBUSinterfaceandCC-Linkinterface,theeldbusprotocolhasbeen
presetatthefactory.
ThemenuforsettingtheeldbusprotocolislocatedintheParameterdetailedview.
ChangetotheParameterdetailedview:
To make the setting with the Bürkert Communicator in the navigation area, select Industrial
communication.
To make the setting on the display,
press menu key 2x.
You are in the detailed view Parameter.
Settingeldbusprotocol:
→ Selecttheeldbusprotocolinthe Protocol menu.
Youhaveselectedtheeldbusprotocol.
