8.4.3 Maximum number of data values (objects)
Fieldbusprotocol Input
values
Output
values
Totalnumber
ofvalues
Input
bytes
Output
bytes
Totalnumber
ofbytes
PROFIBUS DPV1 128 128 244 244 244 244
PROFINET 128 128 256 512 512 1024
EtherNet/IP 128 128 256 504 504 1008
Modbus TCP 128 128 256 512 512 2048
EtherCAT
(ME43 until
A.03.02.00)
128 128 176 512 512 1024
EtherCAT
(ME43 from A.7.5)
128 128 160 512 512 1024
Table 3: Maximum number of data values
8.4.4 General settings for the Gateway conguration
ProcedureintheBürkertCommunicator:
→ Select Industrialcommunication. → Parameter.
→ Select Gatewayconguration → Createagatewayconguration.
File
Edit
View Options
Tools
Desktop
Graph
büS
100%
Help
Gateway ME43
FLOWave
Industrial communication
General settings
Device
MFC_02
MFC_01
-
+
+
+
+
+
-
Industrial communication
MFC_03
ProcessValve_01
COMMUNICATOR
Parameter Diagnostics
Parameter
Creationofagatewayconguration
Protocol selection
CANopen
DeviceNet
EtherCAT
PROFINET
PROFIBUS
EtherNet/IP
ModbusTCP
Editexistingconguration
Startnewconguration
Maintenance
Figure 6: Conguration, select target protocol
→ Select target protocol in the window ProtocolSelection. It is possible to select several protocols.
Whenselectingseveral,thecongurationleswillbecreatedfortheselectedtargetprotocolsbased
onthefollowingIO-valueconguration.
→ Select Editexistingconguration or Startnewconguration.
