Start-up
Type ME43
8.4 Conguration of the eldbus gateway
The “Bürkert Communicator” PC software and the büS stick, which is available as an accessory, are
requiredforconguration,seechapter“15 Accessories”.
The “Bürkert Communicator” software and a general description of it are available on the Bürkert
homepage.
8.4.1 Preparing to congure the eldbus gateway
1.EstablishtheconnectionwiththeBürkertCommunicatorPCsoftware.
Seechapter“9.4.2 Establishing a connection between the device and Bürkert Communicator”
2. OpencongurationareaintheBürkertCommunicator.
→ Select GatewayXXXX in the navigation area.
Toopenthecongurationareas,clickon+.
3.Selecteldbusprotocol.
→ Select Industrialcommunication. → Parameter → Protocol →Selecteldbusprotocol.
Theeldbusprotocolforindustrialcommunicationcanalsobesetonthedisplayofthedevice:
Parameter → Protocol
8.4.2 Methods for generating a Gateway conguration
TherearedierentmethodsforconguringaeldbusgatewayintheBürkertCommunicator.
1. DownloadingtheGatewayconguration.
→ Industrialcommunication. → Parameter. → Gatewayconguration
→ Downladingagatewaycongurationle → Loadgatewaycongurationtodevice
→ Specify storage location.
2.
Automaticgatewayconguration.
→ Industrialcommunication. → Parameter. → Gatewayconguration
→ Createagatewayconguration → Automaticgatewayconguration
→ Specify storage location.
3. RegeneratingaGatewayconguration.
Description of the required steps in the following chapters
“8.4.4GeneralsettingsfortheGatewayconguration” and
“8.4.5DeclaringinputsandoutputsfortheGatewayconguration”.
4.EditingtheexistingGatewayconguration.
  ProcedureidenticaltotheregenerationofaGatewayconguration.
→ Finally,specifythestoragelocationoftheexistingconguration.
