Setting up the büS network
Type ME43
10 SETTING UP THE büS NETWORK
10.1 Conversion Industrial Ethernet to büS
ThefunctionoftheeldbusgatewayistoconverttheprocessvaluesbetweenanIndustrial-EthernetPLC
andbüSdevices.Forthis,theeldbusgatewayME43mustbeconguredandparameterized.
10.2 Theoretical principles for the selection of büS devices
and process values
SelectthebüSdevicesthataretocommunicatewiththePLCviatheeldbusgatewayME43:
büSdevice1
büSdevice2
Fieldbus gateway
Figure 21: Conguration; selection of the büS devices that are to communicate with the PLC
Selectwhichprocessvaluesaretobeconvertedfrom“IndustrialEthernet”to“büS”:
büSdevice1
büSdevice2
Fieldbus gateway
Actualvalue1
Actualvalue2
Set-pointvalue1
Set-pointvalue2
Figure 22: Conguration; selection of the process values that are to be converted from “Industrial Ethernet” to “büS”
