Setting up the büS network
Type ME43
Denethedirectionfortransmissionoftheprocessvalues(from/toPLC,from/tobüSdevice):
ThedirectionisassignedfromtheperspectiveoftheeldbusgatewayME43intheeldbusbüS.
Example:
-Theset-pointvaluesofabüSdevicearetheoutputvaluesoftheeldbusgatewayME43.
-TheactualvaluesofabüSdevicearetheinputvaluesoftheeldbusgatewayME43.
ProcessoutputvaluesofthePLCarereceivedbytheeldbusgatewayME43asprocessinputvaluesvia
Industrial Ethernet. These process input values are converted and provided as process output values via
büS.
Conversely, process output values of the büS device are received as büS input values. These process input
values are converted and output as process output values via Industrial Ethernet.
büSdevice
Fieldbus gateway
Outputvalue Inputvalue
Inputvalue Outputvalue
Outputvalue
Inputvalue
Inputvalue
Outputvalue
Conversion of the process values
IndustrialEthernet büS
Figure 23: Conguration; principle of direction allocation for process values
Based on the type of conversion, büS devices can be addressed directly using their process values and the
direction of conversion.
büSdevice
Outputvalue
Inputvalue
Inputvalue Outputvalue
Continued output data
Continued input data
Figure 24: Conguration; type of conversion for process values from the PLC to the büS device
