G - Graphic Definition - Rectangle
Graphic Type: R - Rectangle
G[:name;]x,y,r,R:width,height[,hlt [,vlt]][,options] CR
G = Graphic field definition command.
[:name;] = Optional field name. Maximum length 10 characters, no special
characters allowed, field name must be unique. The field name
can be used for further operations, such as Replace field name
(See the "R" command for details) or just as a comment.
x = Horizontal coordinate of the start position in millimeters or inches
from the left edge of the printable area to the start point of the line
y = Vertical coordinate of the start position in millimeters or inches
from the left edge of the printable area to the start point of the line
Starting point of rectangles is the upper left corner, outside of the
rectangle
r = Rotation.Rectangles can be rotated in steps of 1degrees
from 0 to 359 degrees. This makes for sure no sense to change
that value for circles. Visible effects will be seen on Ellipses...
R = Rectangle
width = width (horizontal ) of the rectangle in millimeters or inches
height = height (vertical) of the rectangle in millimeters or inches
hlt = horizontal line thickness in millimeters or inches
vertw = vertical line thickness in millimeters or inches
Filled rectangles or ellipses are produced if width is not set
[,options]= ,fill = filling of the graphic object with a specified pattern
or with dot density. (see graphic option "fill")
,shade = shading option (gradient filling - see graphic option
"shade")
,outline = outline option - prints an outline around the filled
graphic object with the thickness of 1 dot. (see
graphic option "outline")
Syntax:
