PRODUCT MARKING AND BARCODE IDENTIFICATION
M-series
[J: ... ] Justification
The J commamd can be used to set the orientation of a text string in a specified area.
[J:ml]
J = Justification
m = l - left
= c -centered
= r - right
l = length of the specified area where the text string will be justified
Positions are measured in millimeters or in inches, whatever is set by the "m" command.
J
S l1;0,0,68,71,100
G:AREA;10,10,0;R:70,10,.2,.2
T:NOADJUST;10,300,0,3,5;cab
T:ADJUST;10,20,0,3,5;cab[J:r70]
A 1
The Field "NOADJUST" is transmitted as is and the Field "ADJUST" adjusts the textline to the right
side of the defined area. (Shown with added rectangle.)
Syntax:
Example:
