CAB A Series User Manual

138 cab Produkttechnik GmbH & Co KG
138
PRODUCT MARKING AND BARCODE IDENTIFICATION
Hermes
Apollo
A-series
This
function is
available
for:
[TABLE OF CONTENTS]
[COMMAND LIST][INDEX][ESC][i][L][S]
M-series
G - Graphic Definition - Circle
Graphic Type: C - Circle, Ellipse
G[:name;]x,y,r;C:radius1[,radius2[,width]][,options] CR
G = Graphic field definition command.
[:name;] = Optional field name. Maximum length 10 characters, no special
characters allowed, field name must be unique. The field name
can be used for further operations, such as Replace field name
(See the "R" command for details) or just as a comment.
x = Horizontal coordinate of the start position in millimeters or inches
from the left edge of the printable area to the center of the circle.
y = Vertical coordinate of the start position in millimeters or inches
from the left edge of the printable area to the center of the circle.
Starting point of Circles and Ellipses is in the center
r = Rotation - Circles and ellipses can be rotated in steps of 1
degrees from 0 to 359 degrees. This makes for sure no sense to
change that value for circles. Visible effects will be seen on
Ellipses...
C = Circle
radius1 = Horizontal radius
radius2 = Vertical radius
width = Width of the circle line in millimeters or inches.
Filled circles or ellipses are produced if width is not set
[,options]= ,fill = filling of the graphic object with a specified pattern
or with dot density. (see graphic option "fill")
,shade = shading option (gradient filling - see graphic option
"shade")
,outline = outline option - prints an outline around the filled
graphic object with the thickness of 1 dot. (see
graphic option "outline")
Syntax:
