PRODUCT MARKING AND BARCODE IDENTIFICATION
M-series
[XM] am/pm indicator
This option was implemented for the usage in countries, where the time is displayed as "am"
(morning) and "pm" (afternoon), when 12 hour time format is selected.
[XM]
am/pm
J
S l1;0,0,68,71,100
T 12,25,0,3,8;The time is [H12]:[MIN] [XM]
A1
Syntax:
Example:
176
178
Table of Contents
Default Chapter
2
