CAB A Series User Manual

cab Produkttechnik GmbH & Co KG 163
163
[TABLE OF CONTENTS]
[COMMAND LIST][INDEX]
Hermes
Apollo
A-series
This
function is
available
for:
[ESC][i][L][S]
PRODUCT MARKING AND BARCODE IDENTIFICATION
M-series
T - Text Field Definition
The most used command to program a label is the "T" command which is used for text field
definitions.This command influences the size, shape, rotation etc. of any shown textlines on a label.
T[:name;]x,y,r,font,size[,effects];text CR
T = Text field definition command.
:name; = A field name can be set for further operations such as replacing
text contents in a predefined text field or for calculations or for
the concetenation of multiple fields. The field name is an
optional parameter. Maximum length 10 digits, ALPHA signs
and digits only. Text field names are case sensitive.
x = horizontal start position - distance from the left starting point of
the label in millimeters or inches.
y = vertical start position - distance from the top margin starting
point of the label in millimeters or inches.
r = Text field rotation. Vector fonts and downloadable true type
fonts can be rotated 360 degrees in steps of 1 degree.
Bitmap fonts can be rotated in 4 directions ( 0, 90, 180 and 270
degrees)
font = specifies a font type, set by a number which might be an
internal printer font (vector or bitmap) or a downloaded true
type
TM
font. Vector fonts are scalable fonts which appear in a
smooth shape when magnified.
Following font types are available:
font nr. Name Type Description
-1 _DEF1 Bitmap Default-size 12x12 dots
-2 _DEF2 Bitmap Default-size 16x16 dots
-3 _DEF3 Bitmap Default-size 16x32 dots
-4 OCR_A_I Bitmap OCR-A Size I
-5 OCR_B Bitmap OCR-B
3 BX000003 Vector Swiss 721
TM
5 BX000005 Vector Swiss 721 Bold
TM
596 BX000596 Vector Monospace 821
TM
Syntax:
