Hermes
Apollo
A-series
This
function is
available
for:
[
ESC
][
i
][
L
][
S
]
PRODUCT MARKING AND BARCODE IDENTIFICATION
M-series
I -
I
mage Field Definition
J
S l1;0,0,68,71,100
I:IMAGE1;20,5,0,0,0;HUMAN
T 12,25,0,3,6;Todays date is: [DATE:+03,+02,+10]
A1
Prints the picture "HUMAN" which had previously downloaded to the printer.
Example:
148
