Hermes
Apollo
A-series
This
function is
available
for:
[ESC][i][L][S]
PRODUCT MARKING AND BARCODE IDENTIFICATION
M-series
no
no
B - Barcode Definition
A-series and M-series printers will print a rastered area if a barcode would not fit on the label. The
printers intelligence checks this for you to avoid later reading problems. This includes also the
required white space for the barcode readability. Check the barcode witdh, height and x / y positions
to make sure that the barcode is placed correct. This improvement is not available for Apollo and
Hermes printers.
The following picture shows what happens when a barcode is misplaced.
A-series printers will print a raster instead of a barcode as demonstrated on the following label in the
lower right corner.
misplaced barcode
