2.13. Internal registers
Table 2.2: Registers map
NAME
ADDRESS
Type
Nbit
Function
STATUS
00
read
16
Status register
VME_CTRL
01
read/write
16
VME control register
FW_REV
02
read only
16
Firmware revision
FW_DWNLD
03
read/write
8
Firmware download
FL_ENA
04
read/write
1
Flash enable
IRQ_STAT
05
read only
7
IRQ status
IRQ_MASK
06
read/write
7
IRQ mask
IN_REG
08
read/write
7
Front panel input register
OUT_REG_S
0A
read/write
11
Front panel output register set
IN_MUX_S
0B
read/write
12
Input multiplexer set
OUT_MUX_S
0C
read/write
15
Output multiplexer set
LED_POL_S
0D
read/write
7
LED polarity set
OUT_REG_C
10
write only
11
Front panel output register clear
IN_MUX_C
11
write only
12
Input multiplexer clear
OUT_MUX_C
12
write only
15
Output multiplexer clear
LED_POL_C
13
write only
7
LED polarity clear
PULSEA_0
16
read/write
16
Period and width of pulser A
PULSEA_1
17
read/write
10
# pulses and range of pulser A
PULSEB_0
19
read/write
16
Period and width of pulser B
PULSEB_1
1A
read/write
10
# pulses and range of pulser B
SCALER0
1C
read/write
11
End Count Limit and Autores of scaler
SCALER1
1D
read only
10
Counter value of scaler
DISP_ADL
20
read only
16
Display AD [15:0]
DISP_ADH
21
read only
16
Display AD [31:16]
DISP_DTL
22
read only
16
Display DT [15:0]
DISP_DTH
23
read only
16
Display DT [31:16]
DISP_PC1
24
read only
12
Display control left bar
DISP_PC2
25
read only
12
Display control right bar
LM_ADL
28
read/write
16
Local monitor AD [15:0]
LM_ADH
29
read/write
16
Local monitor AD [31:16]
LM_C
2C
read/write
9
Local monitor controls
B_ID
36
read
8
Status of the 2 rotary switches for the
board VME base address
