2.13.29. Location Monitor Address Low register
(Base Address + 0x28, D16, read/write)
This register allows to set/monitor the Location monitor Address bits[15..0]; see § 2.7.
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
LMON_AD [15:0]
Fig. 32: Location Monitor Address Low register
2.13.30. Location Monitor Address High register
(Base Address + 0x29, D16, read/write)
This register allows to set/monitor the Location monitor Address bits[31..16]; § 2.7.
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
LMON_AD [31:16]
Fig. 33: Location Monitor Address Low register
2.13.31. Location Monitor Control register
(Base Address + 0x2C, D16, read/write)
This register allows to set/monitor the Location monitor control parameters; see § 2.7
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
ADDRESS_MODIFIER
LWORD
IACK
WRITE
Fig. 34: Location Monitor control register
2.13.32. BA Rotary Switches Status register
(Base Address + 0x36, D16, read)
This register is available from firmware revision 2.17 on. It allows to read the value of the
2 on-board rotary switches (see § 2.6 and § 3.5.1). This information can be used to
identify multiple Bridges connected to a single PC.
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
SW 9
SW 8
Fig. 35: BA Rotary Switches Status register
