3. Technical specifications
3.1. Packaging
The Model V2718 is a 1-unit wide 6U high VME module.
The Mod. A2818 is a 32-bit 33 MHz PCI Bus card
The Mod. A3818 is a PCI Express (v1.1 or higher) Bus card compatible with x8 and x16
PCI Express slot.
3.2. Power requirements
Board
V2718
A2818
A3818
Power
supplies
+5 V
1 A (running)
+3.3V/+5V (jumper selectable
4
)
+12 V / +3.3 V
0.8 A (idle)
-12V
150 mA
(all NIM outputs active)
40 mA
(TTL outputs or outputs not active)
+12V
0 A (connected but not used)
4
The A2818 power supply must be selected according to the used PCI bus DC power supply
(+3.3V/+5V); see § 3.5.2.
