User's Manual (MUT)
Mod. V2718 VME PCI Optical Link Bridge
03/07/2018
11
NPO:
Filename:
Number of pages:
Page:
00106/03:V2718.MUTx/11
V2718_REV11.DOC
79
29
2.13.14. Output Multiplexer Clear register
(Base Address + 0x12, D16, write only)
This register allows to clear the Output Multiplexer settings (1 = Clear, 0 = leave previous
setting)
Fig. 17: Output Multiplexer Set register
2.13.15. LED Polarity set register
(Base Address + 0x0D, D16, read/write)
This register allows to set the LED polarity status (1 = set; 0 = leave previous setting).
Fig. 18: LED Polarity set register
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
OUT_0
OUT_1
OUT_2
OUT_3
OUT_4
IN_0
IN_1
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
OUT0_SOURCE
OUT1_SOURCE
OUT2_SOURCE
OUT3_SOURCE
OUT4_SOURCE
OUT0_POL
OUT1_POL
OUT2_POL
OUT3_POL
OUT4_POL
