3.4. V2718 and A2818/A3818 External components
3.4.1. V2718 connectors
The location of the connectors is shown in Fig. 3.1. Their electromechanical
specifications are listed here below.
TX/RX
5
: Mechanical specifications:
LC type connector; to be used with
Multimode 62.5/125µm cable with LC
connectors on both sides
PROGRAMMABLE In/Out: Mechanical specifications:
LEMO 00 connectors
Electrical specifications:
standard NIM/TTL signals (dip switch
selectable), 50 impedance
3.4.2. V2718 buttons
SYSRES pushbutton: Long touch (>2 s) for SYSRES generation
Short touch for Manual START of Pulsers (see § 3.6.1)
3.4.3. A2818 connectors
The location of the connectors is shown in Fig. 3.1. Their electromechanical
specifications are listed here below.
TX/RX: Mechanical specifications:
LC type connector; to be used with
Multimode 62.5/125µm cable with LC
connectors on both sides.
3.4.4. A3818 connectors
The location of the connectors is shown in Fig. 3.1. Their electromechanical
specifications are listed here below.
TX/RX: Mechanical specifications:
LC type connector; to be used with
Multimode 62.5/125µm cable with LC
connectors on both sides.
5
Two Leds indicate the Link activity: green = connection active, yellow = data transfer
