Caen V2718 - Output Clear Register; Fig. 13: Output Set Register

To Next Page

To Previous Page

Document type:

Title:

Revision date:

Revision:

User's Manual (MUT)

Mod. V2718 VME PCI Optical Link Bridge

03/07/2018

NPO:

Filename:

Number of pages:

Page:

00106/03:V2718.MUTx/11

V2718_REV11.DOC

2.13.10. Output clear register

(Base Address + 0x10, D16, write only)

This register allows to clear the output register pattern (1 = Clear, 0 = leave previous

setting).

Fig. 13: Output set register

15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0

PLSA_START

PLSA_RESET

SCR_GATE

SCR_RESET

OUT0

PLSB_START

PLSB_RESET

OUT1

OUT2

OUT3

OUT4
