3.10. V2718 technical specifications table
Table 3.2: Mod. V2718 technical specifications
Packaging
1-unit wide and 6U high VME module
PC Interface
Optical Link from PCI / PCIe Bus
Transfer rate
7
~ 70 MByte/s using the CONET1 old optical link protocol
~ 80 MByte/s using the CONET2 new optical link protocol
Addressing
A16, A24, A32, CR/CSR, LCK;
ADO, ADOH cycles
Data cycles
D08, D16, D32 for R/W and RMW;
D16, D32 for BLT;
D64 for MBLT
Interrupt cycles
D08, D16, D32, IACK cycles (IRQ[7:1] D08, D16, D32, IACK cycles
(IRQ[7:1] passed from VME to the PCI/PCIe BUS through optical link)
LED display
Data bus, address bus, address modifier, interrupt request, control signals
Panel outputs
5 NIM/TTL programmable (default: DSn, AS, DTACK, BERR, LMON)
Panel inputs
2 NIM/TTL programmable
7
Transfer rate supported in MBLT read cycles (block size = 32 kByte), using a PC host with
Windows XP or Linux.
