p. 27 - Manual FA01274-EN - 11/2018 - © CAME S.p.A. - The contents of this manual may change, at any time, and without notice. Original instructions
RIO PH T2
P1
RIO PH T2
P1
Gate-travel calibration
Confirm? YES
Adding users
Confirm? NO
RIO PH T1
P1
RIO ED T2
P0
RIO ED T1
P0
Language
English (en)
Guided procedure
(Wizard)
Confirm? YES
Opening direction
Left
System type
Single
CY input
C1
input CX
C1
SETTING UP
Once you have finished the electrical connections and installed the limit-switches, have skilled, qualified staff
commission the operator.
Before proceeding, check that the maneuvering area is free of any obstructions, then check that the limit-
switches work properly and that there both opening and closing mechanical stops are in place.
After powering up the system for the first time, perform the preliminary procedures that appear on the display.
1. Select the language you prefer, and confi rm with ENTER.
2. Perform the guided procedure, and confi rm with ENTER.
3. Select the system type [Single] or [Combined], then confi rm with ENTER.
4. Select the gate's opening direction [Left] or [Right], then confi rm with ENTER.
5. Confi gure contact CX as [Disabled], [C1], [C2], [C3], [C4], [C7], [C8], [C13], [r7], [r8], [r7 (two sensitive
safety-edges)] or [r8 (two sensitive safety-edges)], confi rm with ENTER. , , , , , , , , ,
6. Confi gure also for contacts CY, CZ and CK.
7. If the RIOCN8WS module is plugged into the control board, set the function as [Disabled], [P0], [P7] or [P8]
for the wireless device on [RIO ED T1]. , ,
8. Also set the function for the device on [RIO ED T2].
9. Set the function as [Disabled], [P1], [P2], [P3], [P4],o [P13] for the wireless device on [RIO PH T1]. , , ,
Also set the function for the device on [RIO PH T2].
11. Confi rm whether to add the users or not [Confi rm? YES] or [Confi rm? NO], see the [New user] function
on the [Manage users] MENU.
12. Perform the gate travel calibration [Gate-travel calibration], and confi rm with ENTER.
13. The gate will close and open at a constant, reduced speed until it reaches the limit-switches.
14. Then, the gate will close and open at the speeds set up on the [Gate-travel settings] menu, untilthe limit-
switches are reached.
